MAIN TECHNICAL DATA

Anti-drip structure protection class IP22

Insulation class H

Rated voltage 400V/50HZ, 440V/60HZ

Three phase four wire

Stable voltage regulation rate ≤±1%

Transient voltage regulation ≤ -18%~+20%

Voltage waveform distortion rate THD ≤ 3%

Telephone harmonic factor THF≤ 2%

Telephone interference factor TlF ≤ 50

Other standard of voltage can be availableby your request

USING ENVIRONMENT

The alternator can be used in below environment:

Above sea level: not exceed 1000m

Ambient temperatura 258~313K (-15°C~40°C)

Relative humidity: not exceed 90%

CHARACTERISTIC

Selectable magneto alternator and assist exciting winding system can supply the ability to support the short circuit currency

Advanced automatic voltage regulator control system can make the machine to operate reliably under the worst environment

It's easy to parallel connection with other alternator and electric net work. Standard 2/3 pitch winding suppress overfull neutral current

Dynamically balanced rotor is with sealed needle bearing, have both structure of single bearing and double bearings

lt's easy to install and maintain; it has very simple operation of termination, rotary rectifier & coupling nuts

Multi specification for adaptor and couping disc for single bearing

It's suitable to all the standard of land used alternator
